Flexible aseptic filling system

DESCRIPTION
Features
Technical Parameters

This system is installed after the UHT sterilizer and is used for automatic aseptic filling of sterilized materials. The equipment is equipped with a transfer window, a Class 100 aseptic filling room, a collaborative robot, and a servo capping machine. The packaging materials are unpacked and sterilized and then transferred to the filling room through the transfer window. The filling room provides an aseptic filling environment. The collaborative robot and capping machine can realize automatic bottle grabbing, automatic filling, and automatic capping. It can also realize the filling of different bottle types by quickly changing the fixture, which is used for batch production of samples.

▪ Independent working unit.
▪ Equipped with transfer window, which can buffer packaging materials and sterilize with UV ozone.
▪ The air purification level in the filling room can reach Class 100.

▪ The collaborative robot for automatic filling is fully matched with the UHT host.
▪ The fast change of fixtures enables sample filling of different bottle types for batch production of samples.

Collaborative Robot	6 axes/working radius 920mm/load 5kg Support collision detection, drag teaching
Servo Capping Machine	Torque 1.5Nm/speed 180r/min
Aseptic filling room	Meets Federal 209E Class 100 standards
Applicable bottle type	Customizable
Filling speed	Less than 120 bottles/H (10-500ml)
noise	Less than 60db (A)
power supply	Single phase 220 V 50 HZ
Work area size	1220 (L) x700 (W) x800 (H) mm
Overall dimensions	1280 (L) x670 (W) x1930 (H) mm
Work surface	304 Stainless Steel
