The PT-SS Series Experimental UHT Scraper Heat Exchanger fully simulates the industrial scraper heat exchanger production. The equipment includes a heating chamber and a cooling chamber, which can be a single or multi-chamber structure. The heating product temperature can reach up to 150°C. The system can provide superheated water for sterilizing the filling loop. The scraper chamber and scraper surfaces are chrome-plated, and the components in contact with the product are made of 316 stainless steel. The gasket and sealing materials are made of fluororubber. The piping connections use DIN sanitary fittings.

▪ Modular design to meet different customer requirements.
▪ No steam required, only tap water and electricity needed.
▪ Minimum capacity of 5 L/H, maximum capacity customizable according to customer requirements.
▪ Built-in CIP and SIP functions.
▪ Heating temperature up to 150°C, cooling can reach below 5°C.
▪ Capable of online homogenization.
