The machine wildly used for concentration in dairy, dextrose, starch, xylose, pharmaceutical, chemicals, bio-engineering, environmental engineering and devil liquor etc.

Compositions
Warm-up plate,4×Pump,Vacuum pump,Heater,Evaporation chamber,Tube condenser,Raw material tank.

Applications

The machine wildly used for concentration in dairy, dextrose, starch, xylose, pharmaceutical, chemicals, bio-engineering, environmental engineering and devil liquor etc.

* Rated evaporation: 50L / h
* Installed power: ~ 6.05KW
* Feed temperature: room temperature, the material temperature <48℃
* Steam consumption: 22KG / h. pressure of the steam inlet: not less than 7bar
* Cooling water consumption: ~ 1000Kg / h 25 ℃ income, 39 ℃ out.
* Pressure of inlet water :not less than 2bar
* First-effect evaporation temperature: 75 ℃
* Second-effect evaporation temperature: 62 ℃
* Third-effect evaporation temperature: 48 ℃
